fluorocarbon paint fiber cement exterior wall panel | Exterior Wall Panel with Fluorocarbon Paint

Contact Us Send Inquiry Download

Size

Thickness(mm) Width(mm) Length(mm)
6，8，10，12, 15 1220 2440

Parameters

Deviation in width (≤1220mm) ±3mm Deviation in length (≤2440mm) ±4mm
Deviation in thickness: ±0.3mm Density Density: 1.5-1.6g/cm3
Bending strength(Parallel): Average 15 MPa Thermal conductivity: ≤0.29 W/(m.k)
Water absorption: ≤ 25% Moisture movement: ≤ 0.25%
Non-combustibility: GB8624 class A

Our Sanle Exterior Decoration Board – Fluorocarbon paint series structure includes high quality cement board substrate.
Fluorocarbon painting is made by fluorocarbon resin, pigments and additives. It is currently one of the most excellent coating in the market. It is with many excellent functions than the ordinary paint. Its mainly characteristics are weathering resistance, salt fog resistance, washing resistance, acid-proof alkaline, non adhesive, excellent adhesion, easy to burnish and etc.
fluorocarbon paint fiber cement exterior wall panel

Features

*Environmental protection: 100% non-asbestos, will not produce any toxic gases and radiation.
*Fire resistance: excellent flame retardant feature, and prevent the panels form bursting, peeling and cracking by fire.
*Waterproof and anti-corrosion: . owns good waterproof feature
*Resistant to insect and ant: hardening under 11Mpa steam curing, insect and ant can’t live in the board because of its structural characteristics .
*Heat and sound insulation: . Owns good heat insulation and sound insulation effect
*Light weight & high strength fiber cement products is kind of light weight and high: strength materials, owns durable good weather resistance performance .
*Easy working dry installation method, easy and fast : .
*Easy decoration: various decorative processing can be made on the board surface, such as coating materials or all kinds of adhesive

Installation

1. Wall horizontal vertical line positioning.
2.. Install the aluminum trim strip, put the structural adhesive on the back of sanle decoration panel( distance should be about 60cm) , install the vertical T-shape aluminum trim strip? then install the sanle decoration panel in sequence.
3. Install horizontal i-type aluminum trim strip, then install panel and vertical t-type aluminum trim strip.

Note: for waterproof, structural glue is applied in the upward groove of horizontal aluminum trim strip, while structural glue is applied in the two sides of vertical t-type aluminum trim strip. Aluminum trim strip can be installed with self-tapping nails or air nails, spacing 30cm a nail.

4. Install the decoration board and aluminum trim strip in order from up and down or left and right sides, can not leave empty after filling in the middle, corner can use aluminous bag edge profile to close.
